ToyoLex v4 2024 Black Diamond Edition

ToyoLex 4 Black Diamond Edition the first application on the world designed exclusively for DISABLE IMMOBILIZER SYSTEM TROUGH FLASH FILE on Toyota, Lexus and Hino (N04 engines).

PC Unlocked.

It has the following characteristics:

- Supports Generation 1, 2 and 3 files from Toyota and Lexus Denso ECUs with the below MCU cores:

1) Denso Generation 3: R7F701202 and R7F701216.

2) Denso Generation 2: D76F0199GD, D76F0196F1, D76F0219F1.

3) Denso Generation 1: NEC 76F00XX series (currently not support old Denso core 76F0004GD mask found on some 2001-2004 cars).

- Exclusive algorithm that recognizes immobilizer block into flash file, doing the disable task only in such memory and with only one click.

- Automatic special function that do erasing of DTCs togheter with immobilizer disable function.

- By doing the process only in flash memory, most immobilizer disable tasks can be performed through the OBD II port without the need to open the ECU!

- Not more cut / uninstall any wire or module after do immo off, simply program the file generated by ToyoLex 4 BDE and start the engine!

- Support and process files from ALL Denso ECUs for DIESEL and GASOLINE engines.

- Work with ZERO risk on Denso Generation 3 ECUs.

- Allow binary files from any flashing tool of the market that support Denso ECUs for Toyota and Lexus cars.

- Tested on systems with key blade and START-STOP systems.

- Not support ECUs for Hybrid Vehicles and locked Gen 3 ECU by wrong programming (this will be noticed by the application when opening a Hybrid Vehicle file).

- Not tested on Factory virgin ECUs (new ECUs not installed yet).
